E3 SYSTEMS INTEGRATION &
INTEGRATED TOPSIDE DESIGN
ENGINEERING SERVICES

ES provides the multidisciplinary engineering service, Integrated Topside Design (ITD), to optimize placement of topside systems to ensure interoperability with total ship system for antenna coverage, EMI, EMC, RADHAZ, ship and deck operations. ES SMEs review requirements and compliance checks and evaluates the disposition of a system, subsystem, to identify any issues upfront. We advise on MIL-STD E3 testing (e.g., MIL-STD-461, MIL-STD-1605, MIL-STD-1310, MIL-STD-464/EMV, etc.), reviews test plans and reports from other test labs, and provides mitigation solutions for issues found.

HEMP TESTING,
ANALYSIS & DESIGN SERVICES

HEMP testing, analysis, and design, coupled with Hardness Maintenance / Hardness Surveillance (HM/HS), is vital for verifying that HEMP hardness protection subsystems (HPS) in military platforms and facilities meet specifications both when built and throughout their service life. At ES, we specialize in ensuring that Hardness Critical Items (HCI) like filters, SGAs, and conductive aperture covers, are optimized for maximum HEMP survivability. Leveraging extensive HEMP testing and protection design expertise, we offer comprehensive testing, analysis, and design services tailored to military needs. Our testing methodologies, aligned with MIL-STD-4023 and MIL-STD-188-125 series, include Shielding Effectiveness (SE), Pulse Current Injection (PCI), and Low-Level Continuous Wave Illumination (LLCWI) tests. These services are crucial for maintaining the integrity of surface ships and strategic facilities against electromagnetic threats. We utilize a HM/HS database to record and track HEMP-hardness data on key components like cable and conduit penetration SGAs. This repository enables proactive maintenance and ensures continuous platform readiness.

MIL-STD 1310 SHIPBOARD
BONDING, GROUNDING &
SHIELDING

Unwanted radiated electromagnetic (EM) fields can penetrate shielded enclosures through either planned or inadvertent penetrations in the enclosure. The resultant coupled energy can impinge upon below-deck systems through two primary mechanisms: coupled cable currents or radiated EM fields. ES possesses a strong understanding of the recommendations and requirements to harden the ship from unwanted effects of EMI and EMP IAW MIL-STD-1310. We have developed and manufactured specialized equipment that tests and measures the grounding effectiveness of each point of entry and validates that it meets or exceeds the current requirement. If it fails to meet the specification and requires a fix, we offer custom manufactured, reliable solutions to mitigate the problem. We utilize the Data Acquisition and Testing System (DATS), a database-driven software system that enforces quality control on the test team, reducing costs to our customers, driving down schedule requirements, and increasing data reliability.

SHIPBOARD E3
TESTING SERVICES

Electrical components, electronic equipment, and sensors found aboard military ships introduce the risk of EMI that can impact compliance with own-ship EMC. ES provides a wide array of E3 testing services with a strong understanding of the test requirements and the interpretation of the requirements based on years of experience. We conduct field and laboratory tests for conducted emissions and susceptibility, radiated emissions and susceptibility, shielding effectiveness, radiation hazards (HERO, HERP, and HERF), extreme low frequency, ESD, EME survivability and operability, and other E3 compliance testing. Whether your organization needs on site test support and consultation, test monitoring, or field testing, we have the expertise to ensure proper testing and valid results.

TOPSIDE CABLE
INSTALLATION & VERIFICATION

Proper installation and maintenance of hardness critical items (HCI) is a critical component of what the US Navy refers to as the, "layered hardening approach". This approach is to preserve operational availability in an adverse electromagnetic environment and to meet hardness requirements for surface ships. Our SMEs provide guidance on the methods and techniques required to achieve this approach. We have the expertise and manpower for topside cable installation during the pre-construction phase, which saves times and proves cost effective. Our team installs the topside circuits, using correct adapters and hardware, completes any required modifications, then installs and tests the topside POE. The technology used and manufactured by ES provides a proven, reliable solution with significant reduction in weight, for further savings for the shipbuilder.

LAB RESEARCH, DEVELOPMENT,
DESIGN & MANUFACTURING

ES designs and produces tailored prototypes and functional parts for EMI and EMP shielding and protection. We fabricate custom equipment to test grounding effectiveness, engineering and design products that meet the needs of the rapidly changing R&D environment. Our custom products support our customers' timeline and budget requirements. All equipment used are calibrated and rechecked to ensure the accuracy of our design.

THE SCENARIO

Are you a team leader of warfighters on a ship, in a building, vehicle, or aircraft? Are you aware that your team has historically experienced intermittent issues with systems, unable to properly operate or interface with other defensive or offensive systems? Has your team always worked around these problems? Imagine you have been notified that something is coming over the horizon to intercept you and your warfighters. All hands are called to their posts and begin activating the various offensive and defensive combat systems. As a leader, you get a call from the team asking to prioritize the activation of systems to circumvent the threat. You now learn that the way your team has been dealing with these intermittent issues is by deactivating some systems which allow other systems to work. Based on your decision, they caution that the defensive systems, communication systems and/or radar systems may not work properly if all are concurrently operational. You are forced to decide whether to be blind, defenseless, or unable to report back to command.

This situation occurs repeatedly whether on land, sea, or air with systems that have not been properly protected, designed, and tested with EMI in mind. ES has been in the forefront of situations just like this. We have supported the warfighter for over 40 years by preventing this scenario, ensuring EMI and EMP problems does not occur.

ES can design, test, and repair to achieve compliance with the following specifications:

MILITARY STANDARDS &
SPECIFICATIONS

ADS-37A-PRF AERONATURICAL DESIGN STANDARD: ELECTROMAGNETIC ENVIORNMENTAL EFFECTS (E3) PERFORMANCE AND VERIFICATION REQUIREMENTS
DOD-STD-1399 SECTION 070 DEPARTMENT OF DEFENSE INTERFACE STANDARD FOR SHIPBOARD SYSTEMS: DC MAGNETIC FIELD ENVIORNMENT
MIL-DTL-24749B DETAIL SPECIFICATION: GROUNDING STRAPS AND BOSSES
MIL-HDBK-423 HIGH-ALTITUDE ELECTROMAGNETIC PULSE (HEMP) PROTECTION FOR FIXED AND TRANSPORTABLE GROUND-BASED C4I FACILITIES
MIL-PRF-24758A PERFORMANCE SPECIFICATION: CONDUIT SYSTEMS, FLEXIBLE, WEATHERPROOF
MIL-STD-1310 DEPARTMENT OF DEFENSE STANDARD PRACTICE: SHIPBOARD BONDING, GROUNDING, NAD OTHER TECHNIQUES FOR ELECTROMAGNETIC COMPATIBLITY, ELECTROMAGNETIC PULSE (EMP) MITIGATION, AND SAFETY
MIL-STD-1399 SECTION 300 DEPARTMENT OF DEFENSE INTERFACE STANDARD: ELECTRIC POWER, ALTERNATING CURRENT
MIL-STD-1605 DEPARMTNET OF DEFENSE TES TMETHOD STANDARD: PROCEDURES FOR CONDUCTING A SHIPBOARD ELECTROMAGNETIC INTERFERENCE (EMI) SURVEY
MIL-STD-188-125-1 DEPARTMENT OF DEFENSE INTERFACE STANDARD: HIGH-ALTITUDE ELECTROMAGNETIC PULSE (HEMP) PROTECTION FOR GROUND-BASED C4I FACILITIES PERFORMING CRITICAL, TIME-URGENT MISSIONS (PART 1 - FIXED SYSTEMS)
MIL-STD-188-125-2 DEPARTMENT OF DEFENSE INTERFACE STANDARD: HIGH-ALTITUDE ELECTROMAGNETIC PULSE (HEMP) PROTECTION FOR GROUND-BASED C4I FACILITIES PERFORMING CRITICAL, TIME-URGENT MISSIONS (PART 2 - TRANSPORTABLE SYSTEMS)
MIL-STD-2003 DEPARTMENT OF DEFENSE STANDARD PRACTICE: ELECTRIC PLANT INSTALLATION STANDARD METHODS FOR SURFACE SHIPS AND SUBMARINES
MIL-STD-461 DEPARTMENT OF DEFENSE INTERFACE STANDARD: REQUIREMENTS FOR THE CONTROL OF ELECTROMAGNETIC INTERFERENCE CHARACTERISTICS OF SUBSYSTEMS AND EQUIPMENT
MIL-STD-462 DEPARTMENT OF DEFNESE TEST METHOD STANDARD FOR MEASUREMENT OF ELECTROMAGNETIC INTERFERENCE CHARACTERISTICS
MIL-STD-464 DEPARTMENT OF DEFENSE INTERFACE STANDARD: ELECTROMAGNETIC ENVIORNMENTAL EFFECTS REQUIREMENTS FOR SYSTEMS
MIL-STD-704 DEPARTMENT OF DEFENSE INTERFACE STANDARD: AIRCRAFT ELECTRIC POWER CHARACTERISTICS
NASA-STD-4003 ELECTRICAL BONDING FOR NASA LAUNCH VEHICLES, SPACECRAFT, PAYLOADS, AND FLIGHT EQUIPMENT
NAVSEA OD 30393 DESIGN PRINCIPLES AND PRACTICES FOR CONTROLING HAZARDS OF ELECTROMAGNETIC RADIAITON TO ORDNANCE (HERO DESIGN GUIDE)
NAVSEA OD 32382 GROUNDING AND BONDING EQUIPMENT ENCLOSURES, CHASSIS AND CASES, DESIGN AND INSTALLATION
NAVSEA OP 3565/ NAVAIR 16-1-529 VOL 1 TECHNICAL MANUAL ELECTROMAGNETIC RADIATION HAZARDS (HAZARDS TO PERSONNEL, FUEL AND OTHER FLAMMABLE MATERIAL)
NAVSEA OP 3565/ NAVAIR 16-1-529 VOL 2 TECHNICAL MANUAL ELECTROMAGNETIC RADIATION HAZARDS (HAZARDS TO ORDNANCE)
NAVSEA STD 407-5291780 STANDARD ELECTROMAGNETIC INTERFERENCES (EMI) SURVEY PROCEDURES

COMMERCIAL STANDARDS &
SPECIFICATIONS

EU DIRECTIVE 2013/35/EU EU OCCUPATIONAL EXPOSURE TO ELECTROMAGNETIC FIELDS
FCC 47 C.F.R. 1.1307, 1.1310, 2.1091, 2.1093 FCC GUIDLINES FOR HUMAN EXPOSURE TO RADIO FREQUENCY ELECTROMAGNETIC FIELDS
ICNIRP RP EMF 2020 ICNIRP GUIDLINES ON LIMITING EXPOSURE TO ELECTROMAGNETIC FIELDS (100 KHZ TO 300 GHZ)
IEC 60533 STANDARD FOR ELECTRICAL AND ELECTRONIC INSTALLATION IN SHIPS - ELECTROMAGNETIC COMPATIBILITY (EMC) - SHIPS WITH A METALLIC HULL
IEC 61000 SERIES STANDARDS ON ELECTROMAGNETIC COMPATIBILITY
IEEE 299 STANDARD METHOD FOR MEASURING THE EFFECTIVENESS OF ELECTROMAGNETIC SHIELDING ENCLOSURES
IEEE C95.1 STANDARD FOR SAFETY LEVELS WITH RESPECT TO HUMAN EXPOSURE TO ELECTRIC, MAGNETIC, AND ELECTROMAGNETIC FIELDS, 0 HZ TO 300 GHZ
RTCA DO-160 ENVIORNMENTAL CONDITIONS AND TES PROCEDURES FOR AIRBORNE EQUIPMENT
SAFETY CODE 6 2015 CANADA LIMITS OF HUMAN EXPOSURE TO RADIOFREQUENCY ELECTROMAGNETIC ENERGY IN THE FREQUENCY RANGE FROM 3 KHZ TO 300 GHZ

IEC 61000 SERIES
SPECIFICATIONS

IEC/TR EN 61000-1-1 Electromagnetic compatibility (EMC) - Part 1: General - Section 1: Application and interpretation of fundamental definitions and terms
IEC/TR EN 61000-2-1 Electromagnetic compatibility (EMC) - Part 2: Environment - Section 1: Description of the environment - Electromagnetic environment for low-frequency conducted disturbances and signaling in public power supply systems
IEC/TR EN 61000-2-3 Electromagnetic compatibility (EMC) - Part 2: Environment - Section 3: Description of the environment - Radiated and non-network-frequency-related conducted phenomena
IEC EN 61000-3-2 Electromagnetic compatibility (EMC) - Part 3-2 - Limits - Limits for harmonic current emissions (equipment input current ? 16 A per phase)
IEC EN 61000-3-3 Electromagnetic compatibility (EMC) - Part 3-3 - Limits - Limitation of voltage changes, voltage fluctuations and flicker in public low-voltage supply systems, for equipment with rated current ? 16 A per phase and not subject to conditional connection
IEC EN 61000-3-4 Electromagnetic compatibility (EMC) - Part 3-4: Limits - Limitation of emission of harmonic currents in low-voltage power supply systems for equipment with rated current greater than 16 A (note: for currents > 16 A and ? 75 A per phase this standard should be replaced with IEC EN 61400-3-12)
IEC/TS EN 61040-3-5 Electromagnetic compatibility (EMC) - Part 3-5: Limits - Limitation of voltage fluctuations and flicker in low-voltage power supply systems for equipment with rated current greater than 75 A
IEC EN 61040-3-11 Electromagnetic compatibility (EMC) - Part 3-11: Limits - Limitation of voltage changes, voltage fluctuations and flicker in public low-voltage supply systems - Equipment with rated current ? 75 A and subject to conditional connection
IEC EN 61000-3-12 Electromagnetic compatibility (EMC) - Part 3-12: Limits - Limits for harmonic currents produced by equipment connected to public low-voltage systems with input current > 16 A and ? 75 A per phase
IEC EN 61000-4-2 Electromagnetic compatibility (EMC)- Part 4-2: Testing and measurement techniques - Electrostatic discharge immunity test
IEC EN 61000-4-3 Electromagnetic compatibility (EMC)- Part 4-3: Testing and measurement techniques - Radiated, radiofrequency, electromagnetic field immunity test
IEC EN 61000-4-4 Electromagnetic compatibility (EMC) - Part 4-4: Testing and measurement techniques - Electrical fast transient/burst immunity test
IEC EN 61000-4-5 Electromagnetic compatibility (EMC) - Part 4-5: Testing and measurement techniques - Surge immunity test
IEC EN 61000-4-6 Electromagnetic compatibility (EMC) - Part 4-6: Testing and measurement techniques - Immunity to conducted disturbances, induced by radio-frequency fields
IEC EN 61000-4-7 Electromagnetic compatibility (EMC) - Part 4-7: Testing and measurement techniques - General guide on harmonics and interharmonics measurements and instrumentation, for power supply systems and equipment connected thereto
IEC EN 61000-4-8 Electromagnetic compatibility (EMC) - Part 4-8: Testing and measurement techniques - Power frequency magnetic field immunity test
IEC EN 61000-4-9 Electromagnetic compatibility (EMC) - Part 4-9: Testing and measurement techniques - Pulse magnetic field immunity test
IEC EN 61000-4-11 Electromagnetic compatibility (EMC) - Part 4-11: Testing and measurement techniques - Voltage dips, short interruptions and voltage variations immunity tests
IEC EN 61000-4-13 Electromagnetic compatibility (EMC) - Part 4-13: Testing and measurement techniques - Harmonics and interharmonics including mains signaling at a.c. power port, low frequency immunity tests
IEC EN 61000-4-30 Electromagnetic compatibility (EMC) - Part 4-30: Testing and measurement techniques - Power Quality measurement methods
IEC EN 61000-4-34 Electromagnetic compatibility (EMC) - Part 4-34: Testing and measurement techniques - Voltage dips, short interruptions and voltage variations immunity tests for equipment with mains current more than 16 A per phase
IEC EN 61000-6-1 Electromagnetic compatibility (EMC) - Part 6-1: Generic standards - Immunity for residential, commercial and light-industrial environments
IEC EN 61000-6-2 Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity for industrial environments
IEC EN 61000-6-3 Electromagnetic compatibility (EMC) - Part 6-3: Generic standards - Emission standard for residential, commercial and light-industrial environments
IEC EN 61000-6-4 Electromagnetic compatibility (EMC) - Part 6-4: Generic standards - Emission standard for industrial environments
IEC EN 61000-6-5 Electromagnetic compatibility (EMC) - Part 6-5: Generic standards - Immunity for equipment used in power station and substation environment
IEC EN 61000-6-6 Electromagnetic compatibility (EMC) - Part 6-6: Generic standards - HEMP immunity for indoor equipment
IEC EN 61000-6-7 Electromagnetic compatibility (EMC) - Part 6-7: Generic standards - Immunity requirements for equipment intended to perform functions in a safety-related system (functional safety) in industrial locations
IEC EN 61000-6-8 Electromagnetic compatibility (EMC) - Part 6-8: Generic standards - Emission standard for professional equipment in commercial and light-industrial locations

ABOUT US

ES is an ISO-Certified, Veteran-Owned, Small Business (VOSB), and a leading expert in Electromagnetic Environmental Effects (E3) engineering, research & development, testing & evaluation, technical management, and operational deployment since 1982. Founded by Mike Vibbert, a Vietnam Vet with the mission to support the US Navy, our mission has grown to serve many branches of the US Military and commercial clients in the field. We have a team of expert professionals from management, engineering, accounting, customer relations, and technical support to meet any need of our customers.

Mission Statement: ES is dedicated to empowering our customers who protect the warfighter and populations nationwide in meeting challenges of electromagnetic needs through cost-effective and reliable solutions.

Vision Statement: ES' vision is to be the most trusted company in electromagnetic service, protection, and maintenance.

MIKE VIBBERT
CEO & Chief Engineer

Mike served in the US Navy during the Vietnam War where he became a nuclear reactor operator as a submariner. In the 1980's, Mike started consulting for various defense contractors supporting the Navy EMP Authority. In 1982, he created Electronics Service where he developed specialized electromagnetic testing and measurement equipment and began using his knowledge to protect the military from electromagnetic threats.

TRAVIS VIBBERT
COO & Program Manager

Travis joined us in 2004 with a strong background in business systems analysis. He began working with Mike in the RF field performing data administration, acquisition, and rose to head programmer. Travis became a hands-on subject matter expert as he mastered the field of electromagnetics. His strong business background in computer science and finance allowed him to take on the role of Chief Operations Officer and Program Manager for all E3 support contracts, servicing a wide range of commercial, naval and other military clients.

ACCOMPLISHMENTS

  • ISO 9001:2015 Certification
    Electronics Service is proud to be an ISO certified company, reinforcing our high standards of quality services provided to current and future clients.


  • 2023 CTMA Magazine Issue #11, page 36: "Navy Seeks EMI Solutions on Aircraft Carriers"
    Electronics Service's support of the Navy was highlighted in the 2023 article noting our custom software development, test systems, as well as successful grounding and bonding strategies. ES remains dedicated to the Navy fleet and EMI mitigation through research, design, and development. https://www.ncms.org/news/ctma-magazine/

  • CIO Review March 2020: 20 Most Promising Naval Tech Consulting Services Company
    "With over three decades of expertise in RDT&E operations, ES provides engineering and technical consultation for electronic platforms and systems to work hand in hand with Program management, field engineers, data personnel, and stakeholders. By implementing practical solutions and conducting hands-on testing, ES takes the unknowns out of the equation through sound project management, test conduct, data acquisition and analysis, and project administration. This enables organizations to stay mission capable and unharmed from EMP threats or any other electromagnetic disturbances."

  • NATO Innovation Challenge: 2019 Winner
    Electronics Service was one of seven finalists who took part in the Innovation Challenge pitch day and presented their solutions addressing the dangers of electromagnetic pulse before a committee of military and industry experts. Our proactive ideas and solutions addressing the whole spectrum of need identified us as the innovative winner!

  • Ship Electromagnetic Pulse Survivability Trials 1991
    Source: Naval Engineers Journal, Volume 103, Number 3, 1 May 1991, pp. 136-140(5) DOI: https://doi.org/10.1111/j.1559-3584.1991.tb00944.x

PHILANTHROPY

SUPPORTING SPECIAL OLYMPICS

Electronics Service was a proud supporter of the Ingalls 5K on the causeway for the Special Olympics organization. Our commitment to those with disabilities and their daily courage is in line with our culture of continual progression despite the obstacles before us. We are inspired daily by their fearlessness and passion as they strive to push boundaries by participating in the Special Olympics.


SUPPORTING NAVY LEAGUE OF THE UNITED STATES

Electronics Service is honored to be a member of the Navy League of the United States, with our common ideals and shared respect for those patriots who protect everyday Americans with dignity and valor. Together we advocate for those who have given much, and we are proud to stand next to our service members as they continue to stand steadfast against all threats big or small.

EXCITING ROLES WITH US

The next step in your career starts here!

If you strive to advance while supporting those in the frontlines, then come build an exciting future with us. We are actively seeking new team members for:

  • Accounting
  • Business Development & Customer Relations
  • Electrical Engineering
  • Field Technician
  • Project Management
  • RF Engineering
  • Welders & Electricians
